PI sanitary pressure transmitter
Select products

Select the right PI transmitter for your application

The PI1 series of sanitary pressure transmitters from ifm are designed to cover a wide variety of applications, offering the added advantage of real-time data via IO-Link. Browse our available models below to find the one that best suits your needs. Additionally, explore the range of accessories for this product line, including cordsets, process adapters, replacement O-rings, vent protection, and weld fittings. For smooth and efficient installation, refer to our comprehensive installation guidelines to ensure seamless integration into your facility.

PI1 family at a glance
Article No. Aseptoflex Vario	Article No. G1 Sealing Cone	Measuring range		Accuracy		Repeatability
PI1703	PI1803	-1…25 bar	-14.5…362.6 psi	0.0520 bar	0.7540 psi	0.0260 bar	0.3770 psi
PI1704	PI1804	-1…10 bar	-14.5…145 psi	0.0220 bar	0.3190 psi	0.0110 bar	0.1595 psi
PI1705	PI1805	-1…4 bar	-14.5…58 psi	0.0100 bar	0.1450 psi	0.0050 bar	0.0725 psi
PI1706	PI1806	-0.124…2.5 bar	-1.82…36.3 psi	0.0052 bar	0.0762 psi	0.0026 bar	0.0381 psi
PI1707	PI1807	-50…1000 mbar	-20…401.5 inH₂O	2.1000 mbar	0.8430 inH₂O	1.0500 mbar	0.4215 inH₂O
PI1708	PI1808	-12.5…250 mbar	-5…100 inH₂O	0.5250 mbar	0.2100 inH₂O	0.2625 mbar	0.1050 inH₂O
PI1709	PI1809	-1000…1000 mbar	-14.5…14.5 psi	4.0000 mbar	0.0580 psi	2.0000 mbar	0.0290 psi
PI1714	PI1814	-1…16 bar	-14.5…232 psi	0.0340 bar	0.4930 psi	0.0170 bar	0.2465 psi
PI1715	PI1815	-1…6 bar	-14.5…87 psi	0.0140 bar	0.2030 psi	0.0070 bar	0.1015 psi
PI1717	PI1817	-100…1600 mbar	-40...642.5 inH₂O	3.4000 mbar	1.3650 inH₂O	1.7000 mbar	0.6825 inH₂O
PI1718	PI1818	-50…400 mbar	-20…160.6 inH2O	0.9000 mbar	0.3612 inH₂O	0.4500 mbar	0.1806 inH₂O
PI1789	PI1889	-5…100 mbar	-2…40 inH2O	0.5250 mbar	0.2110 inH₂O	0.2100 mbar	0.0844 inH₂O
PI1743	PI1843	-1...40 bar	-14.5...580 psi	0.0820 bar	1.1893 psi	0.0410 bar	0.5947 psi
-	PI1602	-1…100 bar	-14.5…1450 psi	0.5100 bar	7.3200 psi	0.1000 bar	1.4600 inH₂O
-	PI1612	0...160 bar	0...2320 psi	0.800 bar	11.600 bar	0.106 bar	2.321 psi

Cordsets for the PI transmitters
Connector type	Article number	Length
Straight	EVF001 EVF002	5 m 10 m
Right angle	EVF004 EVF005	5 m 10 m

Process adapters for the PI transmitters

Triclamp fittings
Article number	Size	Description
E33208	1.5"	Tri-clamp process adapter for G1 aseptoflex vario
E33209	2"	Tri-clamp process adapter for G1 aseptoflex vario

Weld fittings
Article number	Description	Recommendation	Tank diameter	Wall thickness	Customer benefits
E30528	Weld adapter, 85mm dia.; concave form; 26.5 mm height; 6 mm rim height	For installation in tank heads and walls – recessed sensing face location	> 1.5 m	< 4mm	Recessed sensor location is better drainage when installed in tank head Flanged design adsorbs stresses during welding to keep sealing profile in tolerance Larger 85mm diameter is easier to weld
E30529	Weld adapter, 85mm dia.; convex form; 16.5 mm height; 6 mm rim height	For installation in tank bottoms, walls, larger tank diameters – protruding sensing face location better for drainage off sensing face	> 1.5 m	< 4mm	Protruding location is better for drainage in conical sections or on the bottom of tanks. Flanged design adsorbs stresses during welding to keep sealing profile in tolerance Larger 85mm diameter is easier to weld
E30130	Weld adapter, 50mm dia. straight wall	Standard weld adapter for tanks and pipes with 3A approval	> 1.5 m	4mm	Standard ifm adapter for experienced welders
E30149	Weld adapter, 60mm dia. straight wall	Standard weld adapter for larger tanks and pipes with 3A approval	> 1.5 m	4mm (or less)	Standard ifm adapter for experienced welders with smaller rim height for thinner tank walls

Weld accessories
Article number	Description
E30452	Weld mandrel recommended when installing any of ifm’s weld adapters on tanks or pipes to act as a heat sink and prevent warpage of the weld adapter.
E30160	Grinding protection for welding adapters to protect the sealing edge during weld seam cleanup.

Replacement o-rings
Article number	Material	Description	Supplied with:
E30054	EPDM FDA compliant	EPDM is the most common gasket material used in F&B applications and has a very good suitability with hot water / steam and both acidic / alkaline CIP fluids. This O-ring seals between the face of the process connection and the adapter.	Aseptoflex Vario adapter
E30123	FKM FDA compliant	FKM is very suitable for oil applications as there is minimum swelling even with mineral oils, and it is the most common material for industrial applications with excellent chemical and high temperature resistance.	Optional accessory purchased seperately
E30124	PEEK FDA compliant	PEEK is a more durable seal if devices are removed during the cleaning process, has universal resistance to chemicals, and is more stable than elastomers that become hard and brittle over time.	Optional accessory purchased seperately

Vent accessories
Article number	Description
E30139	Filter cover with tube fitting and vent tube that can be located in a protected and dry area.
E30467	Filter cover with rotatable push to connect fitting, additional plug-in filter cover, and vent tube. Recommended for applications where the end of the vent tube cannot be protected or where chemically demanding external cleaning is conducted.
