OGD laser distance sensor
Select products

OGD laser distance sensor: Select products

The OGD laser distance sensors are ideal for error-proofing applications. They come in robust stainless steel housings for harsh environments and plastic housings for low cost installations. Choose the best solution for your application.

Part No.	Sensing Range	Performance (at 500 mm range)	Interface	Durability	Points to Consider
OGD250	50...2000 mm	Fine mode Accuracy: 5 mm Switching frequency: 20 Hz Standard mode Accuracy: 7 mm Switching frequency: 40 Hz Fast mode Accuracy: 10 mm Switching frequency: 60 Hz	• Pushbuttons • Display • IO-Link	++	Class 1 laser 3 operating modes available Black plastic housing
OGD251				++	Class 1 laser 3 operating modes available Black plastic housing Switching and analog output
OGD550				+++	Class 1 laser 3 operating modes available Stainless steel housing
OGD551				+++	Class 1 laser 3 operating modes available Stainless steel housing Switching and analog output
OGD560	50...4000 mm	Fine mode Accuracy: 3 mm Switching frequency: 15 Hz Standard mode Accuracy: 5 mm Switching frequency: 22 Hz Fast mode Accuracy: 6 mm Switching frequency: 40 Hz	• Pushbuttons • Display • IO-Link	+++	Class 2 laser 3 operating modes Stainless steel housing

Alternative error proofing solutions

Product Family	Housing Size	Sensing Range	Interface	Durability	Points to Consider
OPD Profiler	88x65x29 mm	150...300 mm	• Pushbuttons • Display • IO-Link	+++	• PMD time-of-flight • 0.5 mm accuracy • Distance via IO-Link
O MH laser distance sensor	51x51x17 mm	500 mm	• Pushbuttons • IO-Link	+++	• < 1 mm accuracy at 300 mm range • 1 mm accuracy at 500 mm range • 150 Hz switching frequency • Distance via IO-Link

Browse all ifm laser distance sensors.
