System | Halogen-free |
---|
Operating voltage [V] | 10...30 DC |
---|---|
Max. current load total [A] | 4 |
Ambient temperature [°C] | -25...90 |
---|---|
Protection | IP 68 |
Weight [g] | 65 |
---|---|
Material | TPU (urethane) |
Molded-body material | TPU (urethane) |
Material nut | brass, nickel-plated |
Number of ports splitter box | 2 |
Pack quantity | 1 pcs. |
---|
Cable: 0.25 m, PUR, Halogen-free, black, Ø 5 mm; 5 x 0.25 mm² (32 x Ø 0.1 mm ) |
Connector: 2 x M12, angled; coding: A; Moulded body: TPU (urethane); Locking: brass, nickel-plated |
Connection | Connector: 1 x M12, straight; coding: A; Moulded body: TPU (urethane); Locking: brass, nickel-plated |
---|
