Application | field installation |
---|
Operating voltage [V] | 26.5...31.6 DC |
---|---|
Current consumption [mA] | 15...57; (External supply) |
Max. current consumption from AS-i [mA] | 57; (with external supply: 27 mA) |
Reverse polarity protection | yes |
Additional voltage supply [V] | 24 DC |
Additional voltage supply | optional |
Number of inputs and outputs | Number of analog inputs: 4 |
---|
Sensor supply of the inputs | AS-i/external |
---|---|
Voltage supply [V] | 24 |
Max. total current rating of inputs [mA] | 500; (with external supply; with external supply: 100 mA) |
Digital inputs protected against short circuits | no |
Number of analog inputs | 4; (Anschluss von 2-, 3-, 4-Draht-Sensoren) |
Resolution of analog input | 16 (1 bit = 1 µA) |
Electrical design | AS-i |
---|---|
Resolution of analog output | 1 µA |
Ambient temperature [°C] | 0...70 |
---|---|
Storage temperature [°C] | -20...85 |
Protection | IP 67 |
EMC |
|
---|
AS-i addressing | Addressing socket; IR addressing possible |
---|---|
AS-i profile | S-7.3.E |
AS-i I/O configuration [hex] | 7 |
AS-i ID code [hex] | 3.E |
Weight [g] | 217.2 |
---|---|
Type of mounting | AS-i interface to FC/FC-E lower parts |
Material | PBT; sealing: FKM; screws: stainless steel |
Display |
|
---|
Accessories (optional) |
|
---|
Pack quantity | 1 pcs. |
---|
Connector: M12; coding: A |
