Application
| Pressure rating [bar] | 8 |
|---|
Operating conditions
| Ambient temperature [°C] | -25...80 |
|---|
Mechanical data
| Weight [g] | 83.7 |
|---|---|
| Dimensions [mm] | G 1 1/2 / L = 60 |
| Thread designation | G 1 1/2 |
| Materials | Adapter: POM |
| Sensor connection | clamp adapter Ø 34 mm |
| Process connection | threaded connection G 1 1/2 external thread |
Remarks
| Pack quantity | 1 pcs. |
|---|
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — E11027-00 — 06.03.2003 —
