| Electrical data |
| Operating voltage [V] |
18...30 DC |
| Current consumption [mA] |
< 150 |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Type of light |
red light |
| Wave length [nm] |
650 |
| Typ. lifetime [h] |
50000 |
| Outputs |
| Total number of outputs |
2 |
| Number of digital outputs |
2 |
| Output function |
normally open / normally closed; (programmable) |
| Max. current load per output [mA] |
200 |
| Number of analogue outputs |
1 |
| Analogue current output [mA] |
4...20; (IEC 61131-2) |
| Max. load [Ω] |
250 |
| Analogue voltage output [V] |
0...10; (IEC 61131-2) |
| Min. load resistance [Ω] |
5000 |
| Electrical design |
PNP |
| Short-circuit protection |
yes |
| Type of short-circuit protection |
pulsed |
| Overload protection |
yes |
| Detection zone |
| Max. light spot width [mm] |
8 |
| Max. light spot height [mm] |
8 |
| Light spot dimensions refer to |
6 m |
| Background suppression [m] |
6...100 |
| Measuring/setting range |
| Measuring range [m] |
0.3...6; (white paper 200 x 200 mm) |
| Sampling rate [Hz] |
1...33 |
| Operating conditions |
| Ambient temperature [°C] |
-10...60 |
| Protection |
IP 67 |
| Tests / approvals |
| EMC |
|
| Laser protection class |
1 |
| Notes on laser protection |
| Caution: |
laser light |
| laser class: |
1 |
| IEC 60825-1:2007 |
|
| corresponds to |
21 CFR Part 1040 |
| except for deviations pursuant to Laser Notice No. 50, dated June 2007 |
|
|
| MTTF [years] |
186 |
| Mechanical data |
| Weight [g] |
292 |
| Housing |
rectangular |
| Dimensions [mm] |
59 x 42 x 52 |
| Materials |
housing: diecast zinc; front lens: glass; LED window: PC |
| Displays / operating elements |
| Display |
| switching status |
2 x LED, yellow |
| operation |
LED, green |
| distance value, programming |
alphanumeric display, 4-digit |
|
| Accessories |
| Accessories (optional) |
|
| Remarks |
| Remarks |
| operating voltage "supply class 2" according to cULus |
|
| Pack quantity |
1 pcs. |
| Electrical connection |
| Connection |
Connector: 1 x M12 |
