IO-Link Bluetooth adapter

E30446

IO-LINK INLINE BLUETOOTH ADAPTER

IO-Link Bluetooth adapter

E30446

IO-LINK INLINE BLUETOOTH ADAPTER

  • Transmission of all process values and events from a sensor
  • ifm moneo blue free of charge for iOS and Android
  • Extensive history memory
  • Transparent for IO-Link masters
{{ifmVariantName}}

PDF data sheet
  • ce
  • fcc
  • cul
Technical details
Application
Special feature Gold-plated contacts
Radio approval for USA; Canada; EU/RED; Australia; Japan; Namibia; Brazil; China; India; Singapore; Mexico; South Africa; Malaysia; Vietnam
Note on radio approval
The list of countries applying the European Radio Equipment Directive 2014/53/EU (RED) can be found under “Downloads”.
Electrical data
Operating voltage [V] 18...30 DC
Nominal voltage DC [V] 24
Current consumption [mA] 30...830; (24 V DC, full load)
Protection class III
Reverse polarity protection yes
Software / programming
Parameter setting options process value recording
Interfaces
Communication interface IO-Link; Bluetooth
Bluetooth
Transmission standard BLE 4.0; BLE 4.1; BLE 4.2; EDR 2.0; EDR 2.1
Frequency band 2,4 - 2,482 GHZ
Transmission power [mW] 10; (10 dBm)
Range typ. 20 m
IO-Link Device
Transmission type COM1 (4,8 kBaud); COM2 (38,4 kBaud); COM3 (230,4 kBaud)
IO-Link revision 1.0; 1.1
SDCI standard IEC 61131-9
Required master port type A
Operating conditions
Ambient temperature [°C] -25...60
Storage temperature [°C] -25...70
Protection IP 67
Tests / approvals
EMC
DIN EN 61000-6-2
DIN EN 61000-6-4
Shock resistance
DIN EN 60068-2-27 15 g (6 ms)
Vibration resistance
DIN EN 60068-2-6 2 g (10...150 Hz)
MTTF [years] 285
UL approval
File number UL E205959
Mechanical data
Weight [g] 88.5
Materials stainless steel (1.4404 / 316L); brass (2.0401); PA; PBT; FKM; Sealing: FKM;
Displays / operating elements
Display
operation 1 x LED, green
IO-Link 1 x LED, yellow
Bluetooth 1 x LED, blue
Remarks
Pack quantity 1 pcs.
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — E30446-00 — 23.03.2023 —
