Flush pressure sensor

PM1504

PM-010-REA12-A-ZVG/US

Flush pressure sensor PM1504
Flush pressure sensor PM1504
Flush pressure sensor PM1504
Flush pressure sensor PM1504
Flush pressure sensor PM1504
Flush pressure sensor PM1504

Flush pressure sensor

PM1504

PM-010-REA12-A-ZVG/US

  • Robust stainless steel housing for use in the food and beverage industry
  • Hygienic, flush design
  • Resistant to high-pressure cleaning with aggressive cleaning agents
  • High temperature resistance and high protection rating
  • Integrated temperature measurement via IO-Link
PDF data sheet
  • cmim
  • ce
  • fda
  • ukca
  • ehedg
  • reg31
  • 3a
  • acs
  • fcm
  • iolink
  • cul
  • ec19352004
  • crn
Product characteristics
Measuring range
-1...10 bar -14.5...145 psi -0.1...1 MPa
Process connection threaded connection G 1/2 external thread sealing cone
Application
Special feature Gold-plated contacts
Measuring element ceramic-capacitive pressure measuring cell
Temperature monitoring yes
Application flush mountable for the food and beverage industry
Media viscous media and liquids with suspended particles; liquids and gases
Conditionally suitable for use in gases at pressures > 25 bar only on request
Medium temperature [°C] -25...150
Min. bursting pressure
175 bar 2538 psi 17 MPa
Pressure rating
75 bar 1100 psi 7.5 Mpa
Vacuum resistance [mbar] -1000
Type of pressure relative pressure; vacuum
No dead space yes
MAWP (for applications according to CRN) [bar] 43
Electrical data
Operating voltage [V] 18...30 DC
Min. insulation resistance [MΩ] 100; (500 V DC)
Protection class III
Reverse polarity protection yes
Integrated watchdog yes
2-wire
Current consumption [mA] 3.5...21.5
Power-on delay time [s] < 1
3-wire
Current consumption [mA] < 45
Power-on delay time [s] < 0.5
Outputs
Total number of outputs 2
Output signal analogue signal; IO-Link
Analogue current output [mA] 4...20; (scalable; 1:5)
Max. load [Ω] 700; (Ub = 24 V; (Ub - 9 V) / 21.5 mA)
Short-circuit proof yes
Overload protection yes
Measuring/setting range
Measuring range
-1...10 bar -14.5...145 psi -0.1...1 MPa
Analogue start point
-1...8 bar -14.5...116 psi -0.1...0.8 MPa
Analogue end point
1...10 bar 14.5...145 psi 0.1...1 MPa
In steps of
0.005 bar 0.1 psi 0.0005 MPa
Factory setting
ASP = 0.0 bar AEP = 10.0 bar
Temperature monitoring
Measuring range
-25...150 °C -13...302 °F
Accuracy / deviations
Repeatability [K] ± 0,2
Resolution [K] 0.2
Repeatability [% of the span] < ± 0,1; (with temperature fluctuations < 10 K; Turn down 1:1)
Characteristics deviation [% of the span] < ± 0,5; (linearity incl. hysteresis and repeatability, limit value setting to DIN EN IEC 62828-1)
Linearity deviation [% of the span] < ± 0,15; (Turn down 1:1)
Hysteresis deviation [% of the span] < ± 0,15; (Turn down 1:1)
Long-term stability [% of the span] < ± 0,1; (Turn down 1:1; per year)
Total deviation over temperature range
Temperature range total deviation
-25...15 °C Characteristics deviation ± 0,05 % der Spanne / 10 K
15...80 °C Characteristics deviation
80...150 °C Characteristics deviation ± 0,1 % der Spanne / 10 K
Notes on the accuracy / deviation for further details see section Diagrams and graphs
Temperature monitoring
Accuracy [K] ± 2.5 K + (0.045 x (ambient temperature - medium temperature))
Response times
Damping for the analogue output dAA [s] 0...4
2-wire
Step response time analogue output [ms] 30
3-wire
Step response time analogue output [ms] 7
Temperature monitoring
Dynamic response T05 / T09 [s] < 10 / < 25; (DIN EN 60751 water; > 0,9 m/s)
Interfaces
Communication interface IO-Link
Transmission type COM2 (38,4 kBaud)
IO-Link revision 1.1
SDCI standard IEC 61131-9
Profiles Smart Sensor ED2: Identification and Diagnosis (0x4000), Measurement Data Channel (0x800A)
SIO mode no
Required master port type A; (when pin 2 not connected: B)
Min. process cycle time [ms] 4.5
IO-Link resolution pressure [bar] 0.002
IO-Link resolution temperature [K] 0.2
IO-Link process data (cyclical)
function bit length
pressure 16
temperature 16
device status 4
IO-Link functions (acyclical) application specific tag; internal temperature
Supported DeviceIDs
Type of operation DeviceID
Default 1021
Operating conditions
Ambient temperature [°C] -25...80
Storage temperature [°C] -40...100
Protection IP 67; IP 68; IP 69K
Tests / approvals
EMC
DIN EN 61326-1
Shock resistance
DIN EN 60068-2-27 50 g (11 ms)
Vibration resistance
DIN EN 60068-2-6 20 g (10...2000 Hz)
MTTF [years] 322
Note on approval
factory certificate available as download at www.factory-certificate.ifm
UL approval
UL Approval no. J024
File number UL E174189
Mechanical data
Weight [g] 307.4
Materials stainless steel (1.4404 / 316L); PTFE; FKM
Materials (wetted parts) ceramics (99.9 % Al2O3); stainless steel (1.4435 / 316L); surface characteristics: Ra < 0,4 / Rz 4; PEEK; PTFE
Min. pressure cycles 100 million
Tightening torque [Nm] 20
Process connection threaded connection G 1/2 external thread sealing cone
Remarks
Pack quantity 1 pcs.
Electrical connection
Connection Connector: 1 x M12; coding: A; Contacts: gold-plated
Diagrams and graphs
X temperature
Y total deviation
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — PM1504-01 — 03.08.2023 —
