Product characteristics
Type of light | red light |
---|---|
Housing | rectangular |
Application
Design | Fibre-optic amplifiers for glass fibre optics, for fibre optics with metal sheath, FE/FT-50 |
---|
Electrical data
Operating voltage [V] | 10...30 DC |
---|---|
Current consumption [mA] | < 50 |
Protection class | III |
Reverse polarity protection | yes |
Type of light | red light |
Outputs
Electrical design | PNP/NPN; (automatic load detection PNP/NPN) |
---|---|
Output function | light-on/dark-on mode; (programmable) |
Max. voltage drop switching output DC [V] | 2.5 |
Permanent current rating of switching output DC [mA] | 100 |
Switching frequency DC [Hz] | 1000 |
Short-circuit protection | yes |
Type of short-circuit protection | pulsed |
Overload protection | yes |
Time function [s] | 0.001...0.09 |
Detection zone
Range [m] | 0...1; (Through-beam sensor) | |
---|---|---|
Range [mm] | 0...150; (Diffuse reflection sensor) | |
Factory setting |
|
|
Range adjustable | yes |
Operating conditions
Ambient temperature [°C] | -25...60 |
---|---|
Protection | IP 65 |
Tests / approvals
EMC |
|
||
---|---|---|---|
MTTF [years] | 837 |
Mechanical data
Weight [g] | 47.8 |
---|---|
Housing | rectangular |
Dimensions [mm] | 36 x 15 x 60 |
Materials | PPE modified |
Lens alignment | side lens |
Displays / operating elements
Display |
|
---|
Remarks
Remarks |
|
||||
---|---|---|---|---|---|
Pack quantity | 1 pcs. |
Electrical connection
Connector: 1 x M8; coding: A |
