Application
| Design | for temperature sensors EL = 300 mm |
|---|---|
| Pressure rating [bar] | 400 |
Accuracy / deviations
| Max. permissible flow velocity [m/s] | 25 |
|---|
Mechanical data
| Weight [g] | 1236 |
|---|---|
| Materials | stainless steel (316L/1.4404) |
| Sensor connection | 1/2" NPS Ø 6 mm suitable for G1/2 and 1/2" NPT |
| Process connection | welding adapter Ø 38,1 mm |
| Installation length EL [mm] | 191 |
| Bore length BL [mm] | 228.6 |
Remarks
| Pack quantity | 1 pcs. |
|---|
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — E37430-00 — 16.09.2014 —
