Diffuse reflection sensors with background suppression

OGH202

OGH-HPKG/US100

Diffuse reflection sensors with background suppression

OGH202

OGH-HPKG/US100

  • Robust stainless steel housing for use in harsh industrial environments
  • Precise background suppression
  • Wide range of fixing components for quick and easy mounting
  • Excellent price/performance ratio
{{ifmVariantName}}



  • ce
  • eac
Technical details
Product characteristics
Type of light red light
Housing Threaded type
Dimensions [mm] M18 x 1 / L = 72
Application
System Background suppression
Function principle Diffuse reflection sensor
Electrical data
Operating voltage [V] 10...36 DC
Current consumption [mA] 25
Protection class II
Reverse polarity protection yes
Type of light red light
Wave length [nm] 624
Outputs
Electrical design PNP
Output function light-on mode
Max. voltage drop switching output DC [V] 2.5
Permanent current rating of switching output DC [mA] 200
Switching frequency DC [Hz] 1000
Short-circuit protection yes
Type of short-circuit protection yes (non-latching)
Overload protection yes
Monitoring range
Range [mm] < 100; (white paper 200 x 200 mm 90 % remission)
Range adjustable no
Max. light spot diameter [mm] 9
Light spot dimensions refer to Range
Background suppression available yes
Operating conditions
Ambient temperature [°C] -25...60
Protection IP 67
Tests / approvals
EMC
EN 60947-5-2
MTTF [years] 372
Mechanical data
Weight [g] 52.6
Housing Threaded type
Dimensions [mm] M18 x 1 / L = 72
Thread designation M18 x 1
Material housing: stainless steel; PA; sealing: FKM
Lens material
glass
Displays / operating elements
Display
Switching status 1 x LED, yellow
Accessories
Items supplied
lock nuts: 2 x
Remarks
Pack quantity 1 pcs.
Electrical connection
Connection Connector: 1 x M12
ifm efector, inc. • 1100 Atwater Drive • Malvern • PA 19355 — We reserve the right to make technical alterations without prior notice. — EN-US — OGH202-01 — 20.03.2012 —
