KG5040

Capacitive sensor

KGE2008-FRKG/NI

{{'OPTIONAL_INFO' | productAvailability | error}}

Dear customer,
Unfortunately, this data sheet is not available in the requested language. If you have any further questions, you can contact us by e-mail.

Best regards
Your ifm team

  • Easy setting of the sensing range via potentiometer
  • Output function normally open / normally closed programmable
  • Clearly visible indication of the switching status
  • Two-wire technology
  • With terminal chamber that can be rotated by 90°
  • ccc
  • ce
  • eac
Download
Technische Details
Product characteristics
Electrical design PNP/NPN
Output function normally open / closed; (selectable)
Sensing range [mm] 2.5...8
Housing Threaded type
Dimensions [mm] M18 x 1 / L = 110
Electrical data
Operating voltage [V] 10...55 DC
Protection class II
Outputs
Electrical design PNP/NPN
Output function normally open / closed; (selectable)
Max. voltage drop switching output DC [V] 4.6
Minimum load current [mA] 4
Max. leakage current [mA] 1
Permanent current rating of switching output DC [mA] 200; (400 (...50 °C))
Switching frequency DC [Hz] 50
Short-circuit proof yes
Overload protection yes
Monitoring range
Sensing range [mm] 2.5...8
Sensing range adjustable yes
Factory setting sensing range [mm] 8
Real sensing range Sr [mm] 8 ± 10 %
Operating distance [mm] 0...6.5
Accuracy / deviations
Correction factor glass: 0.4 / water: 1 / ceramics: 0.2 / PVC: 0.2
Hysteresis [% of Sr] 1...15
Switch-point drift [% of Sr] -15...15
Operating conditions
Ambient temperature [°C] -25...80
Protection IP 65
Tests / approvals
EMC
EN 60947-5-2
MTTF [years] 497
Mechanical data
Weight [g] 80.5
Housing Threaded type
Mounting non-flush mountable
Dimensions [mm] M18 x 1 / L = 110
Thread designation M18 x 1
Material PBT
Displays / operating elements
Display
Switching status 1 x LED, yellow
Accessories
Accessories (supplied)
lock nuts: 2
screwdriver: 1
Remarks
Pack quantity 1 pcs.
Electrical connection
Connection terminals: ...2.5 mm²; Cable sheath: Ø 4.5...10 mm; Cable gland: M16 X 1.5
