IM0041

Inductive sensor

IMC2035-ARKA/LS-100AK

{{'OPTIONAL_INFO' | productAvailability | error}}

Dear customer,
Unfortunately, this data sheet is not available in the requested language. If you have any further questions, you can contact us by e-mail.

Best regards
Your ifm team

  • Long sensing range for use in conveying
  • With combined AC/DC output and two-wire technology
  • Robust housing for use in harsh industrial environments
  • Five selectable positions of the sensing face
  • LED display for switching status and operation
  • ccc
  • ce
  • eac
  • cul
Download
Technische Details
Product characteristics
Output function normally open
Sensing range [mm] 35
Housing rectangular
Application
System Increased sensing range
Electrical data
Frequency AC [Hz] 47...63
Operating voltage [V] 20...140 AC / 10...140 DC
Protection class I
Reverse polarity protection yes
Outputs
Output function normally open
Max. voltage drop switching output DC [V] 5.5
Max. voltage drop switching output AC [V] 5.5
Minimum load current [mA] 5.5
Max. leakage current [mA] 1.7 (140 V AC/DC)
Short-time current rating of switching output [mA] 2200; (20 ms / 0,5 Hz)
Switching frequency AC [Hz] 25
Switching frequency DC [Hz] 100
Short-circuit protection yes
Type of short-circuit protection yes (non-latching)
Overload protection yes
Monitoring range
Sensing range [mm] 35
Operating distance [mm] 0...28.3
Increased sensing range yes
Accuracy / deviations
Correction factor steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminum: 0.4 / copper: 0.3
Hysteresis [% of Sr] 3...15
Operating conditions
Ambient temperature [°C] -25...70
Protection IP 67
Tests / approvals
EMC
EN 60947-5-2
MTTF [years] 353
UL approval
Ta 0...40 °C
Enclosure type Type 1
voltage supply Hazardous voltage
File number UL E174191
Mechanical data
Weight [g] 253
Housing rectangular
Mounting non-flush mountable
Material PPE; connector housing: brass; clamp: diecast zinc
Displays / operating elements
Display
Switching status 1 x LED, red
Power 1 x LED, green
Remarks
Remarks
5 positions of the active zone possible
Pack quantity 1 pcs.
Electrical connection - plug
Connector: 1 x 1/2"
