Electrical design | PNP |
---|---|
Output function | normally closed |
Sensing range [mm] | 5.5 |
Housing | Threaded type |
Dimensions [mm] | M12 x 1 |
Operating voltage [V] | 10...36 DC |
---|---|
Current consumption [mA] | < 15 |
Protection class | III |
Reverse polarity protection | yes |
Electrical design | PNP |
---|---|
Output function | normally closed |
Max. voltage drop switching output DC [V] | 2.5 |
Permanent current rating of switching output DC [mA] | 150 |
Switching frequency DC [Hz] | 800 |
Short-circuit protection | yes |
Type of short-circuit protection | yes (non-latching) |
Overload protection | yes |
Sensing range [mm] | 5.5 |
---|---|
Real sensing range Sr [mm] | 5.5 ± 10 % |
Operating distance [mm] | 0...4.45 |
Correction factor | steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminum: 0.4 / copper: 0.3 |
---|---|
Hysteresis [% of Sr] | 1...15 |
Switch-point drift [% of Sr] | -10...10 |
Ambient temperature [°C] | 10...50 |
---|---|
Protection | IP 67 |
EMC |
|
||||
---|---|---|---|---|---|
MTTF [years] | 3069 |
Weight [g] | 58.2 |
---|---|
Housing | Threaded type |
Mounting | non-flush mountable |
Dimensions [mm] | M12 x 1 |
Thread designation | M12 x 1 |
Material | brass white bronze coated; PBT |
Items supplied |
|
---|
Pack quantity | 1 pcs. |
---|
Connection | Cable: 2 m, PVC; 3 x 0.14 mm² |
---|
