Application | Housing for panel mounting |
---|
Operating voltage [V] | 26.5...31.6 DC |
---|---|
Current consumption [mA] | < 50 |
Integrated watchdog | yes |
Number of inputs and outputs | Number of digital inputs: 2 |
---|
Number of digital inputs | 2 |
---|---|
Input circuit of digital inputs | PNP |
Sensor supply of the inputs | AS-i |
Voltage supply [V] | 18...30; (DC) |
Input current High [mA] | > 5 |
Digital inputs protected against short circuits | no |
Electrical design | PNP |
---|---|
Voltage range DC [V] | DC |
Max. current load per output [mA] | 10 |
Short-circuit proof | no |
Actuator supply outputs | AS-i |
Ambient temperature [°C] | -25...60 |
---|---|
Protection | IP 20; (depending on the housing) |
EMC |
|
||
---|---|---|---|
MTTF [years] | 842 |
AS-i version | 2.11; 3.0 | ||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|
Extended addressing mode | yes | ||||||||||
AS-i master profile | M2; M3; M4 | ||||||||||
AS-i profile | S-7.A.E | ||||||||||
AS-i I/O configuration [hex] | 7 | ||||||||||
AS-i ID code [hex] | A.E | ||||||||||
AS-i certificate | 75101 | ||||||||||
Data bits |
|
Weight [g] | 58.5 |
---|
Display |
|
---|
Pack quantity | 1 pcs. |
---|
Cable: 0.2 m |
