Wirable plug
E12775
SSTGB030ZDSFKPG
Wirable plug
E12775
SSTGB030ZDSFKPG
{{ifmVariantName}}
| Application | ||
|---|---|---|
| Special feature | Gold-plated contacts | |
| Electrical data | ||
| Operating voltage [V] | < 300 AC/DC | |
| Protection class | II | |
| Max. current load total [A] | 12 | |
| Operating conditions | ||
| Ambient temperature [°C] | -25...85 | |
| Protection | IP 67 | |
| Mechanical data | ||
| Weight [g] | 51.9 | |
| Moulded-body material | PBT | |
| Material nut | diecast zinc, nickel-plated | |
| Remarks | ||
| Remarks |
|
|
| Pack quantity | 1 pcs. | |
| Electrical connection | ||
| screw terminals: ...1.5 mm²; Cable sheath: Ø 6...8 mm; AWG 16 | ||
| Electrical connection - plug | ||
| Connection | Connector: 1 x 7/8", straight; Moulded body: PBT; Locking: diecast zinc, nickel-plated; Contacts: gold-plated | |
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — E12775-00 — 04.10.2022 —
|
||
E12775 –
SSTGB030ZDSFKPG
Electrical connection
screw terminals: ...1.5 mm²; Cable sheath: Ø 6...8 mm; AWG 16
Electrical connection - plug
Connector: 1 x 7/8", straight; Moulded body: PBT; Locking: diecast zinc, nickel-plated; Contacts: gold-plated
