Gasket
E30492
SEAL RING ISO1179-2 G1/2 FKM
Gasket
E30492
SEAL RING ISO1179-2 G1/2 FKM
- For reliably sealing tanks, containers and pipes
- For use in combination with process sensors
{{ifmVariantName}}
Application
| Design | for units with process connection G ½ |
|---|
Operating conditions
| Ambient temperature [°C] | -15...200 |
|---|
Tests / approvals
| Standard | DIN EN ISO 1179-2 |
|---|
Mechanical data
| Weight [g] | 3.4 |
|---|---|
| Inside diameter [mm] | 18.5 |
| External diameter [mm] | 23.9 |
| Materials | FKM |
Remarks
| Pack quantity | 5 pcs. |
|---|
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — E30492-00 — 22.12.2020 —
