| Application | |
|---|---|
| Function principle | Through-beam sensor |
| Detection zone | |
| Range with fibre optic amplifier type | OBF; ODF; OMF |
| OBF | |
| Range of fibre optics [mm] | 1000 |
| ODF | |
| Range of fibre optics [mm] | 4 |
| OMF | |
| Range of fibre optics [mm] | 800 |
| Operating conditions | |
| Ambient temperature [°C] | -58...315 |
| Mechanical data | |
| Weight [g] | 174 |
| Version of sensing head | angled |
| Sensing head diameter [mm] | 5 |
| Total length [mm] | 900 |
| Min. bending radius [mm] | 19 |
| Fibre arrangement | |
| Fibre material | glass |
| Fibre head material | stainless steel (1.4305 / 303) |
| Fibre sheath material | stainless steel (1.4305 / 303) |
| Remarks | |
| Pack quantity | 1 pcs. |
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — E20828-00 — 04.06.2003 —
|
|
