| Product characteristics | |||||
|---|---|---|---|---|---|
| Type of light | infrared light | ||||
| Housing | rectangular | ||||
| Dimensions [mm] | 28 x 16 x 51 | ||||
| Application | |||||
| Function principle | Through-beam sensor | ||||
| Electrical data | |||||
| Operating voltage [V] | 10...55 DC | ||||
| Current consumption [mA] | 20; ((24 V)) | ||||
| Protection class | II | ||||
| Reverse polarity protection | yes | ||||
| Type of light | infrared light | ||||
| Wave length [nm] | 880 | ||||
| Outputs | |||||
| Short-circuit protection | yes | ||||
| Type of short-circuit protection | pulsed | ||||
| Overload protection | yes | ||||
| Detection zone | |||||
| Transmitter / receiver | transmitter | ||||
| Range [m] | < 6 | ||||
| Range adjustable | no | ||||
| Max. light spot diameter [mm] | 734 | ||||
| Light spot dimensions refer to | at maximum range | ||||
| Operating conditions | |||||
| Ambient temperature [°C] | -25...80 | ||||
| Protection | IP 67 | ||||
| Tests / approvals | |||||
| EMC |
|
||||
| MTTF [years] | 1801 | ||||
| Mechanical data | |||||
| Weight [g] | 138 | ||||
| Housing | rectangular | ||||
| Dimensions [mm] | 28 x 16 x 51 | ||||
| Materials | PPO modified | ||||
| Lens material |
|
||||
| Lens alignment | side lens | ||||
| Displays / operating elements | |||||
| Display |
|
||||
| Accessories | |||||
| Accessories (supplied) |
|
||||
| Remarks | |||||
| Pack quantity | 1 pcs. | ||||
| Electrical connection | |||||
| Connection | Cable: 2 m, PVC; 2 x 0.34 mm² | ||||
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — OU5005-00 — 06.03.2003 —
|
|||||
