Product characteristics
| Electrical design | PNP |
|---|---|
| Output function | normally open |
| Dimensions [mm] | 26.1 x 2.8 x 5.5 |
Electrical data
| Operating voltage [V] | 10...30 DC |
|---|---|
| Current consumption [mA] | < 10 |
| Protection class | III |
| Reverse polarity protection | yes |
| Max. power-on delay time [ms] | 30 |
Outputs
| Electrical design | PNP |
|---|---|
| Output function | normally open |
| Max. voltage drop switching output DC [V] | 2.5 |
| Permanent current rating of switching output DC [mA] | 100 |
| Switching frequency DC [Hz] | 5000 |
| Short-circuit protection | yes |
| Overload protection | yes |
Detection zone
| Response sensitivity [mT] | 2 |
|---|---|
| Travel speed [m/s] | < 10 |
Accuracy / deviations
| Hysteresis [mm] | 1 |
|---|---|
| Repeatability [mm] | < 0.2 |
Operating conditions
| Ambient temperature [°C] | -25...85 |
|---|---|
| Protection | IP 65; IP 67 |
Tests / approvals
| EMC |
|
||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| MTTF [years] | 2064 | ||||||||||
| UL approval |
|
Mechanical data
| Weight [g] | 8.7 |
|---|---|
| Mounting | flush mountable |
| Cylinder type | C-slot cylinders |
| Dimensions [mm] | 26.1 x 2.8 x 5.5 |
| Materials | housing: PA; fastening clamp: stainless steel |
| Tightening torque [Nm] | < 0.24 |
Displays / operating elements
| Display |
|
|---|
Remarks
| Pack quantity | 1 pcs. |
|---|
Electrical connection - plug
| Connection | Cable: 0.15 m, PUR |
|---|---|
| Connection | Connector: 1 x M8; coding: A; Locking: snap-fit |
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — MK5343-01 — 13.04.2023 —
