AS-Interface flat cable splitter

E7377A

FC Splitter ye/ye II 3D/3G

AS-Interface flat cable splitter

E7377A

FC Splitter ye/ye II 3D/3G

  • Reliable distribution of the AS-i voltage or the external 24 V supply
  • Hygienic design for the requirements of the food and beverage industry
  • Easy and quick connection due to insulation displacement technology
  • Resistant to high-pressure cleaning with aggressive cleaning agents
  • For applications in hazardous areas
  • ce
  • ukca
  • ex
Application
Application for the distribution of the AS-i voltage or the external 24 V supply
Electrical data
Protection class III
Max. current load total [A] 8
Outputs
Electrical design AS-i
Operating conditions
Ambient temperature [°C] 0...60
Note on ambient temperature
-15...60 °C: only in connection with an EPDM cable
Max. relative air humidity [%] 80; (31 °C; linearly decreasing to 50 % (40 °C))
Max. height above sea level [m] 2000
Protection IP 67; (when used outside the hazardous area: IP 68 / IP 69K)
Pollution degree 2
Tests / approvals
ATEX marking II 3G Ex ec IIC T6 Gc X
II 3D Ex tc IIIC T 70°C Dc X
Mechanical data
Weight [g] 132.5
Materials metal parts: stainless steel (1.4404 / 316L); rubber gasket for contact pins: FKM; Sealing: EPDM
Tightening torque [Nm] 2.5; (Mounting screw)
Accessories
Accessories (optional)
Torque wrench:, E70390
flat cable blank:, E70299
Remarks
Pack quantity 1 pcs.
