| Application | |
|---|---|
| Design | for climatic tube LK, LI |
| Installation | Clamp fitting |
| Pressure rating [bar] | 0.5 |
| Operating conditions | |
| Ambient temperature [°C] | 0...80 |
| Mechanical data | |
| Weight [g] | 258.5 |
| Materials | stainless steel; NBR; brass |
| Tightening torque [Nm] | 6...8 |
| Sensor connection | Ø 22 mm |
| Process connection | threaded connection 1" NPT |
| Remarks | |
| Pack quantity | 1 pcs. |
