IO-Link data splitter

E43410

IO-LINK DATA SPLITTER NPN

IO-Link data splitter E43410
IO-Link data splitter E43410
IO-Link data splitter E43410
IO-Link data splitter E43410
IO-Link data splitter E43410
IO-Link data splitter E43410

IO-Link data splitter

E43410

IO-LINK DATA SPLITTER NPN

Order using myifm to benefit from a discounted flat rate delivery charge, irrespective of the number of items in the order.
PDF data sheet
  • ce
  • ukca
  • iolink
  • cul
Product characteristics
Number of inputs and outputs Number of digital outputs: 1
Application
Special feature Gold-plated contacts
Application for retrofitting of existing IO-Link systems; for systems without IO-Link capabilities
Electrical data
Operating voltage [V] 18...30 DC; (on the master side; on the controller / system: 20...30 DC)
Nominal voltage DC [V] 24
Current consumption [mA] < 17; (both sides)
Protection class III
Reverse polarity protection yes; (on the master side)
Power-on delay time [s] < 2; (for communication; response time switching signal: response time device plus IO-Link process cycle time)
Inputs / outputs
Total number of inputs and outputs 1; (on the controller / system)
Number of inputs and outputs Number of digital outputs: 1
Outputs
Output signal switching signal; IO-Link
Electrical design NPN
Number of digital outputs 1
Output function normally open / normally closed
Max. voltage drop switching output DC [V] 2.5
Permanent current rating of switching output DC [mA] 200
Type of short-circuit protection pulsed
Short-circuit proof yes
Overload protection yes
Interfaces
Communication interface IO-Link
Supported DeviceIDs
Type of operation DeviceID
Default 1107
IO-Link Device
Note on interfaces
connection to IO-Link masters
Unterstützte Masterportklasse A
Transmission type COM2 (38,4 kBaud)
IO-Link revision 1.1
SDCI standard IEC 61131-9
Profiles Identification and Diagnosis (0x4000)
SIO mode yes
Min. process cycle time [ms] 4.2
IO-Link Master
Note on interfaces
connection to IO-Link devices
Unterstützte Masterportklasse A / B
Transmission type COM1 (4,8 kBaud); COM2 (38,4 kBaud); COM3 (230,4 kBaud)
IO-Link revision 1.0; 1.1
SDCI standard IEC 61131-9
Operating conditions
Ambient temperature [°C] -25...60
Storage temperature [°C] -25...70
Protection IP 67
Tests / approvals
EMC
DIN EN 61000-6-2
DIN EN 61000-6-4 in plastic or open metal tanks
Shock resistance
DIN EN 60068-2-27 15 g (6 ms)
Vibration resistance
DIN EN 60068-2-6 2 g (10...150 Hz)
MTTF [years] 307
UL approval
File number UL E205959
Mechanical data
Weight [g] 89
Materials stainless steel (1.4404 / 316L); brass (2.0401); PBT; PA; Sealing: FKM;
Displays / operating elements
Display
switching output 1 x LED, yellow
operation 1 x LED, green
IO-Link 1 x LED, yellow
Accessories
Accessory required
Y connection cable 1, EVC843
Remarks
Remarks
For information on the maximum cable length please refer to the operating instructions.
To ensure the function according to technical datasheet and operating instructions the use of the following article is imperative: EVC843
Pack quantity 1 pcs.
