Radio approval for | USA; Canada; EU/RED; Australia; China; South Korea; Japan; Taiwan; Singapore; Malaysia; India | |
---|---|---|
Note on radio approval |
|
Operating voltage [V] | 19.2...28.8 DC |
---|---|
Current consumption [mA] | 500 |
Protection class | III |
Operating frequency [MHz] | 13,56 |
RFID standard | ISO 15693 |
Max. current load per output [mA] | 100; (max.) |
---|
Distance write/read head front [mm] | 600 | ||||||
---|---|---|---|---|---|---|---|
Distance write/read head side [mm] | 850 | ||||||
Note on distance write/read head |
|
||||||
Distance to the ID tag [mm] |
|
Communication interface | Ethernet |
---|
Protocol | EtherNet/IP |
---|---|
Usage type | data transmission |
Protocol | TCP/IP | |||
---|---|---|---|---|
Factory settings |
|
|||
Usage type | parameter setting; data transmission |
Ambient temperature [°C] | -20...60 |
---|---|
Storage temperature [°C] | -25...80 |
Protection | IP 67 |
Shock resistance |
|
||||
---|---|---|---|---|---|
Vibration resistance |
|
||||
MTTF [years] | 130 |
Weight [g] | 640.5 |
---|---|
Dimensions [mm] | 113 x 118.5 x 50 |
Materials | PBT / PC; stainless steel; aluminium |
Display |
|
---|
Pack quantity | 1 pcs. |
---|
ETH1 / ETH2 | Connector: 2 x M12; coding: D |
---|
PWR | Connector: 1 x M12; coding: A |
---|
