Switched-mode power supply 24 V DC

DN1030

PSU-1AC/24VDC-1,3A

Switched-mode power supply 24 V DC

DN1030

PSU-1AC/24VDC-1,3A

  • For the regulated power supply for controllers, sensors, actuators, and industrial electronics
  • Low power loss thanks to high efficiency
  • High mains buffering time
  • Particularly space-saving design
  • Low heating of the control cabinet
  • ce
  • ukca
  • cul
  • cruus
Electrical data
Operating voltage tolerance [%] 10
Nominal voltage AC [V] < 230
Nominal frequency AC [Hz] 47...63
Input voltage range AC [V] 100...240
Output voltage DC [V] 24...28
Protection class II; (IEC 61140)
Power-on delay time [s] < 0.255
Output voltage [V] adjustable
Max. output current at min. output voltage [A] 1.25
Number of output circuits 1
Max. residual ripple [mV] 50
Efficiency (nominal voltage 230 V AC / 50 Hz) [%] 84
External input protection 10 A; B
Derating [W/K] 2% / K (> 60° C)
Mains buffering time (nominal voltage 230 V AC / 50 Hz) [ms] 120
Outputs
Short-circuit proof yes
Overload protection yes
Reliability of the DC OK signal 24 V DC (30 mA)
Operating conditions
Ambient temperature [°C] 0...70
Protection IP 20
Tests / approvals
EMC
EN 61000-6-2
EN 61000-6-3
Mechanical data
Weight [g] 278.5
Type of mounting rail; (TH35 (EN 60715); free space for convection cooling 30 mm)
Dimensions [mm] 90 x 45 x 100
Materials PC ABS
Displays / operating elements
Display
DC ok 1 x LED, green
Remarks
Remarks
output voltage to SELV, PELV
Pack quantity 1 pcs.
Electrical connection
Connection cage clamps:
