| Electrical data |
| Operating voltage [V] |
8...32 DC |
| Current consumption [mA] |
< 400 |
| Reverse polarity protection |
yes |
| Inputs / outputs |
| Total number of inputs and outputs |
60 |
| Number of inputs and outputs |
Number of digital inputs: 32; Number of analogue inputs: 16; Number of frequency inputs: 8; Number of resistor inputs: 4; Number of digital outputs: 27; Number of analogue outputs: 1 |
| Inputs |
| Number of frequency inputs |
8 |
| Number of resistor inputs |
4 |
| Number of digital inputs |
32 |
| Number of analogue inputs |
16 |
| Analogue input (current) [mA] |
0...20 |
| Analogue input (voltage) [V] |
0...32 |
| Outputs |
| Number of digital outputs |
27 |
| Number of analogue outputs |
1 |
| Analogue voltage output [V] |
0...10 |
| Short-circuit protection |
yes |
| Number of PWM outputs |
27 |
| Number of PWM-I outputs |
18 |
| Number of outputs with H-bridge |
3 |
| Software / programming |
| Parameter setting options |
input/output functions |
| PLC function to IEC 61131-3 |
yes |
| Interfaces |
| Number of CAN interfaces |
4 |
| Number of Ethernet interfaces |
1 |
| Number of R232 interfaces |
1 |
| Operating conditions |
| Storage temperature [°C] |
-40...85 |
| Protection |
IP 65; IP 67; (in conjunction with a corresponding connector) |
| Safety classification |
| Complies with the requirements |
| ISO 13849-1: 2015 PL d |
| IEC 62061 SIL 2 |
|
| Mechanical data |
| Weight [g] |
1525.5 |
| Type of mounting |
free-standing |
| Dimensions [mm] |
219 x 47 x 203 |
| Accessories |
| Items supplied |
| Protective cap: M12 |
| self-tapping screw: 1 x M4, for shield connection |
|
| Remarks |
| Pack quantity |
1 pcs. |
