PMD Profiler
Quality inspector ready for all challenges
The final quality of a product is determined by the greatest equivalence possible between specification and implementation in each individual production step. Does that sound complicated? From now on it won't as the PMD Profiler is the answer to all the tricky challenges of your inline quality control. It only takes a few steps for the photoelectric sensor to be ready for use and identify the contour of an object via laser line scan in order to detect any components, installation procedures, grooves or bore holes that do not comply with the target status with a deviation of only 0.5 millimetres being detected. In other words: In future, your products will be manufactured with the maximum quality at each manufacturing step. Simply and safely!
Why opt for the PMD Profiler?
 |
 |
 |
 |
| Set up in just a few steps | Distance independent | Immunity to extraneous light | Simplified fault analysis via IO Link |
| Quick installation with standard M12 connection and optionally even without any software | High tolerance on object positioning | No screening against ambient light or external illumination required | Optional contour visualisation through use of software, for analysis of bad parts |
Sorting and orientation
Error proofing applications
- Differentiate between parts, which optically can hardly be told apart
- Reliably detect and reject bad parts
- Monitor the correct position of objects during the running process
Advantages
- Early detection and elimination of sources of failure
- Minimise the reject rate in the long term
- Avoid consequential damage that would have resulted from installation of bad parts
Correct and complete assembly
Assembly applications
- Checking the complete and correct installation of components
- Checking the correct installation of, for example, sealing rings or the tightening of screws
Advantages
- Detect incomplete components and, if applicable, retrofit
- Readjust or reject incorrectly installed components
- Prevent leakages or instabilities
Gap control
Check if the seals are completely in place
- Check whether fasteners are latched completely
- Focus the contour comparison on the relevant profile area
Advantages
- Detect and, if applicable, correct incorrectly installed components
Processing control
Checking the processing steps
- Differentiate between machined and unmachined parts by comparing their contour
Advantages
- The surface structure allows conclusions about potential faults in the installation (e.g. unmachined workpieces due to a machine fault)
Increase product quality and production efficiency thanks to the PMD Profiler
 |
Minimise installation complexity and cost Plug & play solution for set up in just a few steps |
|
Improve product quality Ensure correct and complete assembly and processing Higher |
|
Higher production efficiency Inline quality control prevents complications in the production line |
|
Permanent reduction of the reject rate Early detection and elimination of sources of failure |
