Product characteristics
Number of inputs and outputs | Number of analogue outputs: 1 |
---|---|
Process connection | threaded connection M18 x 1,5 internal thread |
Application
Media | Liquids |
---|---|
Medium temperature [°C] | -25...80 |
Pressure rating [bar] | 30 |
Electrical data
Operating voltage [V] | 19...36 DC |
---|---|
Current consumption [mA] | < 60 |
Protection class | III |
Reverse polarity protection | yes |
Power-on delay time [s] | 10 |
Inputs / outputs
Number of inputs and outputs | Number of analogue outputs: 1 |
---|
Outputs
Total number of outputs | 1 |
---|---|
Output signal | analogue signal |
Number of analogue outputs | 1 |
Analogue current output [mA] | 4...20 |
Max. load [Ω] | 500 |
Overload protection | yes |
Measuring/setting range
Flow range [cm/s] | 3...250 |
---|---|
Greatest sensitivity [cm/s] | 3...100 |
Accuracy / deviations
Repeatability [cm/s] | 1...5 | ||
---|---|---|---|
Note on repeatability |
|
||
Temperature drift [cm/s x 1/K] | 0.1; (for water 5...100 cm/s; 10...70 °C) |
Response times
Response time [s] | 1...10 |
---|
Operating conditions
Ambient temperature [°C] | -25...80 |
---|---|
Storage temperature [°C] | -25...100 |
Protection | IP 67 |
Tests / approvals
EMC |
|
||||||||
---|---|---|---|---|---|---|---|---|---|
Shock resistance |
|
||||||||
Vibration resistance |
|
||||||||
MTTF [years] | 238 |
Mechanical data
Weight [g] | 228.3 |
---|---|
Housing | cylindrical |
Dimensions [mm] | Ø 50 / L = 113 |
Materials | stainless steel (316L/1.4404); stainless steel (301/1.4310); PC; PBT-GF20; EPDM/X |
Materials (wetted parts) | stainless steel (316L/1.4404); O-ring: FKM 80 Shore A |
Process connection | threaded connection M18 x 1,5 internal thread |
Probe diameter [mm] | 8.2 |
Installation length EL [mm] | 45 |
Displays / operating elements
Display |
|
---|
Remarks
Pack quantity | 1 pcs. |
---|
Electrical connection
Connection | Connector: 1 x M12; coding: A |
---|
