Process adapter Varivent
E43306
ADAPT G1/2-VARIVENT D50
Process adapter Varivent
E43306
ADAPT G1/2-VARIVENT D50
- For the installation of process sensors in containers and pipes
- Easy, quick and secure mounting
- Particularly suited for use in hygienic applications
- Stainless steel adapter for the requirements of the food and beverage industry
- High pressure rating
{{ifmVariantName}}
| Application | |
|---|---|
| Pressure rating [bar] | 25 |
| Mechanical data | |
| Weight [g] | 367 |
| Materials | stainless steel (1.4435 / 316L) |
| Sensor connection | G 1/2 sealing cone |
| Process connection | Varivent Form F, DN25 (1"), Ø 50 mm |
| Surface characteristics Ra/Rz of the wetted parts | 0.4 / 4 |
| Remarks | |
| Pack quantity | 1 pcs. |
