Progressive ring fitting
E33433
PROGRESSIVE RG FITTING D6/M12x1.0
Progressive ring fitting
E33433
PROGRESSIVE RG FITTING D6/M12x1.0
- Quick and easy mounting of temperature sensors
- User-friendly setting of the requested immersion depth of the sensor
- Robust design for use in harsh industrial environments
- High pressure rating
{{ifmVariantName}}
| Application | |
|---|---|
| Installation | Progressive ring fitting |
| Pressure rating [bar] | 50 |
| Tests / approvals | |
| Pressure Equipment Directive | A possible classification to PED depends on the application and has to be carried out by the user / operator. |
| Pressure Equipment Directive EAC | The adapter is intended for use in devices, machines and installations that do not fall under the categories of the technical rule TR CU 032/2013. |
| Safety instructions | The compatibility between medium and product material has to be checked in all applications. |
| Mechanical data | |
| Weight [g] | 34.6 |
| Materials | stainless steel (1.4571/316Ti ) |
| Sensor connection | Ø 6 mm |
| Process connection | threaded connection M12 x 1 |
| Remarks | |
| Pack quantity | 1 pcs. |
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — E33433-00 — 19.08.2014 —
|
|
