Elektrische uitvoering | PNP |
---|---|
Uitgangsfunctie | maakcontact |
Schakelafstand [mm] | 1,5 |
Behuizing | cilindrisch schroefdraad |
Afmetingen [mm] | M8 x 1 / L = 20 |
Voedingsspanning [V] | 10...30 DC; ("supply class 2" volgens cULus) |
---|---|
Stroomopname [mA] | 10; (24 V) |
Beschermklasse | III |
Ompoolbeveiligd | ja |
Elektrische uitvoering | PNP |
---|---|
Uitgangsfunctie | maakcontact |
Max. spanningsval schakeluitgang DC [V] | 1,5 |
Continue stroombelasting van schakeluitgang DC [mA] | 100 |
Schakelfrequentie DC [Hz] | 4000 |
Kortsluitbeveiliging | ja |
Uitvoering kortsluitbeveiliging | pulserend |
Beschermd tegen overbelasting | ja |
Schakelafstand [mm] | 1,5 |
---|---|
Reële schakelafstand (Sr) [mm] | 1,5 ± 10 % |
Werkafstand [mm] | 0...1,2 |
Correctiefactor | staal: 1 / roestvast staal: 0,75 / messing: 0,45 / aluminium: 0,4 / koper: 0,3 |
---|---|
Hysterese [% van Sr] | < 15 |
Schakelpuntdrift [% van Sr] | -10...10 |
Omgevingstemperatuur [°C] | -25...70 |
---|---|
Beschermklasse | IP 67 |
EMC |
|
||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|
MTTF [jaren] | 480 | ||||||||||
UL-goedkeuring |
|
Gewicht [g] | 50,55 |
---|---|
Behuizing | cilindrisch schroefdraad |
Inbouwwijze | bondig inbouwbaar |
Afmetingen [mm] | M8 x 1 / L = 20 |
Schroefdraadtype | M8 x 1 |
Materialen | behuizing: messing vernikkeld; actief vlak: LCP |
Weergave |
|
---|
Leveringsomvang |
|
---|
Verpakkingseenheid | 1 stuk |
---|
Aansluiting | Kabel: 2 m, PVC; 3 x 0,14 mm² |
---|
