Application
| Special feature | Free from silicone; Halogen-free; Gold-plated contacts; Drag chain suitability |
|---|---|
| Free from silicone | yes |
Electrical data
| Operating voltage [V] | 10...30 DC; ("supply class 2" to cULus) |
|---|---|
| Protection class | II |
| Max. current load per module/slot [A] | 4 |
| Max. current load total [A] | 12 |
Outputs
| Electrical design | PNP |
|---|
Operating conditions
| Ambient temperature [°C] | -25...80 |
|---|---|
| Ambient temperature (moving) [°C] | -5...60 |
| Protection | IP 67; IP 68 |
Tests / approvals
| UL approval |
|
|---|
Mechanical data
| Weight [g] | 530.6 | ||||
|---|---|---|---|---|---|
| Dimensions [mm] | 22 x 54 x 100 | ||||
| Materials | PA | ||||
| Moulded-body material | PA | ||||
| Number of ports splitter box | 6 | ||||
| Connector type | M12 | ||||
| Drag chain suitability | yes | ||||
| Drag chain suitability |
|
Displays / operating elements
| Display |
|
|---|
Accessories
| Items supplied |
|
|---|
Remarks
| Pack quantity | 1 pcs. |
|---|
Electrical connection
| Cable: 5 m, PUR, Halogen-free, black, Ø 7.8 mm; 6 x 0.34 mm² (43 x Ø 0.1 mm ) + 3 x 1 mm² (55 x Ø 0.15 mm ) |
Electrical connection - slot
| Connection | Connector: 6 x M12; coding: A; Moulded body: PA; Contacts: gold-plated; Tightening torque: 0.8...1.5 Nm |
|---|
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — EBC019-01 — 05.11.2020 —
