Operating conditions
| Ambient temperature [°C] | -40...70 |
|---|
Mechanical data
| Weight [g] | 452.5 |
|---|---|
| Total length [mm] | 50000; (wirable) |
| Min. bending radius [mm] | 30 |
| Fibre arrangement |
|
| Fibre diameter [mm] | 1 |
| External diameter [mm] | 2.2 |
| Fibre material | PMMA |
| Fibre sheath material | PE |
Remarks
| Pack quantity | 1 pcs. |
|---|
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — E20774-01 — 20.08.2010 —
